Ford Escort RS2000 Cortina 2.0 Pinto BHP30+ Fast Road Piper Cam Camshaft Kit


Ford Escort RS2000 Cortina 2.0 Pinto BHP30+ Fast Road Piper Cam Camshaft Kit. High Torque Fast Road Profile with New 2026 Ramp Design. The Pinto BHP30+ is the updated evolution of our high torque fast road camshaft for the Ford Pinto SOHC. Retaining the proven power characteristics of the original BHP30, the new 2026 lobe profile introduces refined ramp geometry and improved valve control to deliver stronger mid range torque, improved high RPM stability and enhanced valvetrain durability. This cam is designed to produce proper usable performance, strong from low revs and pulling cleanly through to 6500rpm, without turning the engine into a peaky and temperamental race setup.

With the correct supporting modifications, engines fitted with the BHP30+ are capable of producing up to 135bhp with excellent road manners. This is not a cheap cast replacement cam. It is produced from genuine performance cam blanks and ground using modern CNC profiling to ensure consistency, accuracy and longevity.

The BHP camshaft range is manufactured by Piper Cams, ensuring. Accurate phasing and base circle control. High quality cam core material. Excellent cam to cam repeatability. The cam you install is the cam you build and tune around. Power Band: 1000 to 6500 RPM. Valve Lift: 12.24mm Inlet / 11.91mm Exhaust. Valve Clearances: 0.20mm Inlet / 0.25mm Exhaust. Strong low and mid range torque.

Stable idle for a performance cam. When paired with suitable supporting modifications such as carburetion, compression ratio, exhaust system and cylinder head work, outputs of up to 135bhp are achievable. The BHP30+ introduces a revised 2026 lobe acceleration profile while retaining the proven timing events. New or correctly matched followers advised. Vernier pulley strongly recommended for accurate phasing.

Piston to valve clearance must always be checked. Correct installation is critical to performance and longevity.
